Alcor OMEA 9M All Sky Camera

Our price

$13,905.00

Sale Sold out

Type Mono

Calculate shipping cost | shipping promo

Contact for shipping quote

Quantity

Product description

The OMEA camera is our flagship camera that embeds a dome heating system, based on environment humidity and temperature.

Parameter	Value
Field of view	180° x 180° Wavelength range: 400 to 750 nm (IR cut filter) Wavelength range for 4M : 400 to 900 nm (No IR cut filter) Any filter type can be installed : please contact us! Factory focused and tilt tuned with respect to the whole image sensor field.
Camera resolution	9575 x 6380 3.8 µm pixel size (Rolling shutter) All monochrome or color, progressive scan, anti-blooming sensor.
ADC resolution	16 Bits
Video stream	ALL Cameras have video stream capabilities Video file stream can be created 1.5 fps USB 2.0 - 3.5 fps USB 3.0 e is disabled for cooled camera !
Exposure time	From 32µs to one hour exposure (All-Sky mode, typically 20s to 75s)
Gain	Variable, Logarithmic mode from 30x to 10000x
Dome	BK7 Glass optical dome
Image download time	650 ms Max
Auto-iris	Yes
Remote re-focusing	Yes
Image Sensor Cooling	Yes
Control software	ALCOR SYSTEM's All Sky software supplied at no additional costs.
Operating system	Windows 32 & 64 bits (0 and 11) Linux (contact us) SDK available
To PC interface	USB 2.0 + 20 m length cable, perfectly full time reliable operation. Ethernet link on request. USB 3.0 + 15 m length cable, on request (this has added value only in video stream mode)
Bandwith	410 to 690 nm
Top dome heater	Automatic dome defrost based on provided external temperature and humidity sensors. User tunable heating power from 18W to 36W
Power supply	24V / 3A (Power supply provided)
Other informations	Enduring bad weather conditions (rain/snow), anodized aluminum casing, acrylic dome, water tight connectors and body / IP67 protection
Weight	5 kg
Dimensions	Ø130mm x 270 mm
Operating temperature range	from -35°C to +45°C
