SKU:ASALP4C

ALPHEA 4C

Name: ALPHEA 4C
Brand: Alcor
SKU: ASALP4C
Price: 3600.00 USD
Availability: InStock

Our price

$3,600.00

Sale Sold out

Calculate shipping cost | shipping promo

Contact for shipping quote

Quantity

Product description

ALPHEA camera is our entry market camera, low cost, featuring high sensitivity camera using backside illuminated CMOS sensors

ALPHEA 4C Specifications:

Parameter	Value
Field of view	180° x 180 ° See images above to assess this performance
Camera resolution	ALPHEA 4M - 3800 x 2100 (8 Mpixels) 2.9 x 2.9 µm pixel ALPHEA 4C - 3500 x 3500 (12 Mpixels) 2.0 x 2.0 µm pixel All Backside illuminated CMOS sensor (BSI) Ultra low readout noise. No mechanical shutter - All cameras have rolling shutter
ADC resolution	12 bits
Video stream	(USB 2.0) ALPHEA 4M : 7 fps and ALPHEA 4C : 3 fps AVI output or snap image mode
Exposure time	From 32µs to many hours of exposure (all sky mode, typically 30s to 60s)
Gain	Variable (from 1e- / ADU down to 0.05 e- / ADU)
Gamma	Tunable +50 units to -50 units
Cooling	Passive from camera body dissipation, no active cooling
Image download time	< 20 ms
Control software	ALCOR SYSTEM Windows AllSky software supplied at no additional costs, SDK on request
Operating system	Windows (10 & 11) 32 & 64bits Linux (contact us, SDK available)
To PC interface	USB 2.0 / 20 m length cable, perfectly reliable operation.
Top dome heater	Manual enable/disable operation from the user, heat is injected to remove dome dew. Glass dome
Power supply	PC powered, 24V and 0.1A
Bandwidth	ALPHEA 4M : 410 to 690 nm ALPHEA 4C : 400nm to 700 nm ALPHEA 4M Nir option : 380 to 1000 nm
Daylight imaging	ALPHEA 4xx Capable
Auto-iris	None, fixed F/1.6 lens Day operation possible with ALPHEA 4xx with lowest gain and exposure time (32µs)
Focus adjustment	None, factory tuned
Other informations	Tight to bad weather conditions (rain/snow), anodized aluminum casing, acrylic dome, metal M12 connectors, water tight connectors / IP67 protection
Weight	1.5 kg
Dimensions	125mm diameter, 120 mm height
Operating temperature range	from -40°C to +45°C
